A smarter workspace
Gain the versatility to create your ideal workspace and boost your AI PC productivity with support for up to 4 displays, up to 130W power delivery, and multiple ports to connect all your peripherals.
Remotely manageable
Elevate the IT management experience with no software or PC connection required, allowing you to remotely manage all your Dell Pro Smart Docks.
Remotely manageable
Remotely manage your smart docks without end-user presence from the Dell Device Management Console - a holistic peripheral management solution that configures, deploys, and updates smart docks over Wi-Fi.
Work securely
Keep users working confidently with enterprise-grade WPA-3 192-bit encryption for secure Wi-Fi communication. Safeguard your sensitive data with tamper-resistant, hardware-based encryption built into your Dell Pro Smart Dock.
Effortless maintenance
Reduce IT efforts by scheduling updates during off-hours, while ensuring fleetwide firmware compliance and eliminating end user interruptions.
Connect your way
Configure your workspace to your liking with an ambidextrous USB-C cable[1] that can be routed left or right.
Designed for sustainability
The Dell Pro Smart Dock is built with post-consumer recycled materials and packaged with recycled or renewable packaging.
- General Information
- Manufacturer
- Dell Technologies
- Manufacturer Website Address
- http://www.dell.com.au
- Brand Name
- Dell
- Product Type
- Docking Station
- Warranty
- Limited Warranty
- 3 Year
- Additional Warranty Information
- 3-Year Limited Hardware Warranty with Advanced Exchange
- Additional 4- & 5-year warranty optional
- Technical Information
- Connectivity Technology
- Wired
- Device Supported
- Desktop PC
- Notebook
- Cable Length
- 90 cm
- Features
- Power Delivery Pass-through
- Management Features
- Port Disablement
- MAC Address Pass-through
- PXE Boot
- Dock Power Button Sync
- Wake-on-LAN
- WLAN to LAN Switch
- Kernel Direct Memory Access (DMA) Protection
- Number of Displays Supported
- 4
- Screen Mode Supported
- WQHD @ 60Hz
- 5K @ 60Hz
- 6K @ 60Hz
- 4K @ 60Hz
- QHD @ 60Hz
- FHD @ 60Hz
- HD
- Supported Resolutions
- 3440 x 1440
- 5120 x 2160
- 6144 x 3456
- 3840 x 2160
- 2560 x 1440
- 1920 x 1080
- 1280 x 720
- Maximum Data Transfer Rate
- 1.25 GB/s
- Security Slot Type
- Kensington Security Slot
- Power Delivery Details
- 4 x USB-A 3.2 Gen 2 (4.5W each)
- 1 x USB-C 3.2 Gen 2 (15W)
- 1 x USB-C Multi-function DisplayPort (7.5W)
- All deliver power with or without PC
- Power Delivery
- 96W (non-Dell Systems)
- 130W (Dell Systems)
- Video Resolution Details
- FHD - 60 Hz (Triple Display)
- QHD - 60 Hz (Dual Display)
- 4K - 60 Hz (Single Display)
- WQHD - 60 Hz (Quad Display)
- WQHD - 60 Hz (Triple Display)
- 5K - 60 Hz (Dual Display)
- 6K - 60 Hz (Single Display)
- HD - 60 Hz (Quad Display)
- Network & Communication
- Ethernet Technology
- 2.5 Gigabit Ethernet
- Interfaces/Ports
- Host Interface
- USB Type C
- Total Number of USB Ports
- 6
- Number of USB 3.2 Gen 2 Type-A Ports
- 4
- Number of USB Type-A Ports
- 4
- Number of USB Type-C Ports
- 2
- USB Type-A
- Yes
- USB Type-C
- Yes
- USB Type-C Detail
- 1 x USB-C 3.2 Gen 2 (15W), 1 x USB-C Multi-function DisplayPort (7.5W)
- Network (RJ-45)
- Yes
- Number of DisplayPorts
- 2
- DisplayPort
- Yes
- DisplayPort Version
- 1.4
- Number of HDMI Ports
- 1
- HDMI
- Yes
- HDMI Version
- 2.1
- Software
- Operating System Supported
- Windows 10
- Windows 11
- Ubuntu 24.04
- Red Hat Enterprise Linux 9.6
- ChromeOS
- Power Description
- Maximum Power Supply Wattage
- 180 W
- Power Source Type
- Power Adapter
- Physical Characteristics
- Height
- 205 mm
- Width
- 90 mm
- Depth
- 35.3 mm
- Weight (Approximate)
- 562 g
- Miscellaneous
- Package Contents
- Pro Smart Dock SD25
- Power Adapter
- Power Cord
- Documentation (Quick Start Guide, Safety, Environmental, and Regulatory Information)
- Kensington Security Slot
- Yes
- Post-consumer-waste%
- 65%
