The Vertiv Edge Lithium Ion uninterruptible power supply (UPS) is designed to safeguard critical equipment in server rooms, network closets and other edge and distributed IT applications. This 1.5 kVA UPS offers lower total cost of ownership, which can be up to 50% savings over lifetime. Lithium-ion batteries have greater power density, last about 2-3 times as long, recharge quicker and endure up to x10 more discharge cycles than traditional valve-regulated-lead-acid (VLRA) batteries. It includes automatic voltage regulation (AVR) technology to further extend battery life and provides plenty of runtime on battery during an outage for an orderly shutdown. This set-it-and-forget-it single phase UPS system comes with a five-year standard warranty for UPS and batteries, and together with the optional webcard for remote management, becomes ideal for remote or unmanned locations. This rack/tower UPS comes with a rotating LCD display to allow both rack and tower configurations.
- General Information
- Manufacturer
- Vertiv
- Manufacturer Website Address
- http://www.vertiv.com/
- Brand Name
- VERTIV
- Product Line
- Edge Lithium Ion
- Product Type
- Line-interactive UPS
- Warranty
- Limited Warranty
- 5 Year
- Technical Information
- AVR
- Yes
- Plug/Connector Type
- IEC 60320 C14
- Receptacle Type
- IEC 60320 C13
- Receptacle Detail
- 6 x IEC 60320 C13
- Dataline Protection
- No
- Protection Type
- Sag
- Surge
- Spike
- Transient
- Under Voltage
- Over Voltage
- Input Breaker
- Bypass Switch
- No
- Emergency Power OFF
- Yes
- Transfer Time
- 6 ms
- EMI/RFI Noise Filter
- Yes
- Phase
- Single Phase
- Application/Usage
- Server Room
- Network Closet
- IT Equipment
- Business-critical System
- Power Description
- Load Capacity (VA)
- 1.50 kVA
- Load Capacity (Watt)
- 1.35 kW
- Extra Power for Future Expansion
- No
- Input Voltage
- 230 V AC
- Input Voltage Range
- 166 V AC - 278 V AC
- Input Current
- 10 A
- Output Voltage
- 200 V AC
- 208 V AC
- 220 V AC
- 230 V AC
- 240 V AC
- Input Frequency
- 65 Hz
- Power Consumption
- 16.80 W
- Waveform Type
- Sinusoidal
- Surge Energy Rating
- 624 J
- Circuit Breaker
- Yes
- Management
- Alarm
- Yes
- Controls/Indicators
- Status Indicators
- LCD Display
- Diagnostic LEDs
- Interfaces/Ports
- Serial Port
- No
- VGA
- No
- Modem (RJ-11)
- No
- Network (RJ-45)
- No
- USB
- Yes
- USB (HID Compliant) Port
- Yes
- Total Number of Expansion Slots
- 1
- Battery Information
- DC System Voltage
- 48 V DC
- Number of Batteries
- 1
- Battery Chemistry
- Lithium Ion (Li-Ion)
- Battery Capacity
- 5000 mAh
- Backup/Run Time (Full Load)
- 8.70 Minute
- Backup/Run Time (Half Load)
- 18.50 Minute
- Backup/Run Time (With Optional Battery)
- No
- Battery Life
- 5 Year
- Typical Battery Recharge Time
- 1.70 Hour
- Hot Swappable
- Yes
- Environmental Conditions
- Maximum Operating Temperature
- 40°C
- Storage Temperature
- -10°C - 45°C
- Maximum Operating Elevation
- 3 km
- Sound Emission (A-Weighted)
- 45 dB(A)
- Thermal Dissipation
- 47 BTU/h
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Height
- 86 mm
- Width
- 438 mm
- Depth
- 410 mm
- Rack Height
- 2U
- Form Factor
- Rack/Tower
- Weight (Approximate)
- 12.80 kg
- Miscellaneous
- Package Contents
- Edge UPS 1500VA 230V Li-ion
- Rail Kit
- Tower Stand
- QIG
- Safety Sheet
- Output Power Cables
- Input Power Cables
- USB Cable
- Additional Information
- Up to 3 times longer battery life
- Lowest TCO in the industry
- 5-year standard warranty on UPS and batteries
- Up to 10 minutes of runtime at full load (3kVA)
- Recharge to 90% in as little as 2 hours
- 45% Lighter
- 0.9 Power Factor
- Up to 10x more discharge cycles
- Sound Emission: <45dBA AVR mode, >70% load
- Country/Region: EMEA-APAC
- Battery Life: >5 years
- Protection Type: Outages
- Certifications & Standards
- CE
- EAC
- RCM
- CB Report
- ISTA 2A
- UN38.3
- Software Included
- Vertiv Power Assist, Vertiv Power Insight
- Energy Star
- No
- Country of Origin
- China
- TAA Compliant
- No
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
- Waste Electrical and Electronic Equipment Directive (WEEE)
- Restriction of Hazardous Substances (RoHS) 2
- Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
